Products

Presure Vessel Steel

  • Asme SA 516 GR 60/65/70
  • BS1501 224-490B LT50
  • P355NI1/NH
  • P460NL

Chrome Plate

  • 16Mo3
  • A387 Gr11 Ci2

Structural Steel

  • S355J2+N/K2+N
  • 300WA
  • 350WA
  • S275JR
Pressure Vessel steel according to DIN EN 10028-3
DIN Material No Plate Thickness (mm) Width (mm) Length (mm)
P275NH 1,0487 5 - 130 1,000 - 4,000 upto 16,000
P275NH1 1,0488 5 - 130 1,000 - 4,000 upto 16,000
P275NH2 1,1104 5 - 130 1,000 - 4,000 upto 16,000
PN355N 1,0562 5 - 220 1,000 - 4,000 upto 16,000
PN355NH 1,0565 5 - 220 1,000 - 4,000 upto 16,000
PN355NL1 1,0566 5 - 220 1,000 - 4,000 upto 16,000
PN355NL2 1,1106 5 - 220 1,000 - 4,000 upto 16,000
PN460NH 1,8935 5 - 180 1,000 - 3,000 upto 16,000
PN460NL1 1,8915 5 - 180 1,000 - 3,000 upto 16,000
PN460NL2 1,8918 5 - 180 1,000 - 3,000 upto 16,000
Heat treatable and case hardening steels according to DIN EN 10083 / 10084
DIN Material No Plate Thickness (mm) Width (mm) Length (mm)
C45 1,0503 2 - 150 1,000 - 3,000 upto 14,000
C60 1,0601 2 - 150 1,000 - 3,000 upto 14,000
40 CrMo 4 1,7225 3 - 200 1,000 - 2,500 upto 12,500
16 MnCr 5 1,7131 3 - 200 1,000 - 2,500 upto 12,500
20 MnCr 5 1,7147 5 - 200 1,000 - 2,500 upto 12,500
Steels according to ASTM / ASME
Grade Plate Thickness (mm) Width (mm) Length (mm)
A/SA 516 Gr60 3 - 300 1,000 - 4,000 upto 16,000
A/SA 516 Gr70 3 - 220 1,000 - 4,000 upto 16,000
A/SA 387 Gr11 CI.2 6 - 150 1,000 - 3,000 upto 16,000
A/SA 387 Gr12 CI.2 2 - 150 1,000 - 3,000 upto 14,000
A/SA 387 Gr22 CI.2 4 - 120 1,000 - 2,500 upto 14,000
A/SA 283 Gr. C 3 - 120 1,000 - 2,500 upto 16,000
A/SA 285 Gr. C 3 - 120 1,000 - 2,500 upto 16,000
A/SA 387 Gr.5 CI.2 5 - 80 1,000 - 2,500 upto 15,000
